11-20MM T2.9

LIGHTER THAN EVER, WIDER THAN EVER

Image by Eric Estrada

Image by Eric Estrada

TOKINA CINEMA ATX 11-20MM T2.9 WIDEANGLE ZOOM LENS

Image by Johannes Helms

Image by Johannes Helms

Introducing the all new Tokina Cinema 11-20mm T2.9 ATX. This cinema style lens is made for modern digital cinema production with a super wide field of view and compact yet fully featured all metal build.

The new 11-20mm features a cinema style focus throw with 0.8 Mod cinema gears on the focus, zoom and iris rings. Made with an industry standard 95mm front ring for clamping onto a matte box as well as an 86mm filter thread, it is ready for easy filtration options whether using a standard matte box or challenging shooting conditions where a low profile filter is required.

Featuring the Tokina Cinema Vista Lens Mount that can be easily exchanged from PL, EF, Sony E, MFT and Nikon F, in minutes for maximum versatility with common cinema and still/cinema hybrid cameras.

The parfocal optical design allows for zoom racking without loss of focus. The distortion is very well controlled and limited chromatic aberration when shooting at maximum wide open aperture. The lens design also features Super35 sensor coverage.

In total, the Tokina Cinema 11-20mm ATX is the perfect do all compact super wide angle lens for today’s demanding and ever changing digital cinema production environment.

Image by Neil Fernandez

Image by Neil Fernandez


1120_PL_3 WHITED.jpg
11-20mm PL Side.jpg
PL EF MFT E F
Focal Distance 11-20mm
Zoom Ratio 1.82:1
Optical Structure 12 groups / 14 Elements
Image Circle ⌀30.0mm
Minimum Focus Distance 0.30m (1 ft)
Maximum Macro Magnification 1 : 9.65
Aperture/Iris Blades 9
Depth of Field T2.9 - T22 (f2.8-f22)
Filter Size ⌀86mm
Overall Length
(from mounted surface)
99.6mm
(86mm)
99.5mm
(94mm)
123mm
(118.8mm)
125.2mm
(120mm)
99.5mm
(91.5mm)
Diameter of Front Head ⌀95mm
Maximum Diameter ⌀97.6mm
Weight LBS
KG
2.27
103
2.45
1.11
2.58
1.17
2.58
1.17
1.72
0.78
